3.2.2 Internal view
46 A29246-X20-X-4-7680 / fa301.fm
1 side door of fuser station
2 Stacker operator panel
3 Fuser station
4 Front door of fuser station
5 Paper transporter
6 Cover hood
7 Transfer corotron cartridge
8 Photoconductor drum
9 Discharge corotron cartridge
10 Cleaning brush
11 Operator panel on paper transporter
12 Touchscreen operator panel
13 Floppy disk drive
14 Charge corotron cartridges
15 Front right door
16 Developer station
17 Front left door
18 Rocker
19 Stacker top
20 Stacker tray
