4.3.4 Starting and completing the replacement of consumables and expendables
A29246-X20-X-4-7680 / fa405.fm 93
3. Perform all the displayed steps in the given order.
Icons
The icons on the left-hand side show the type of the current step:
Answer a query at the operator panel.
Perform a mechanical adjustment of the printing system.
This step is carried out by the printing system without the operator's
involvement.
The icons on the right side indicate the progress:
This step is currently being executed.
The progress display is automatically moved forward for step types and
.
The progress display is not automatically moved forward for step type . To
display the details of the next step, you must switch to the next step by clicking
the mouse.
This step has not been performed yet and is still to be carried out.
This step was successfully completed.
This step was not completed successfully.
The steps are described in more depth under "Details".
Additional Help for the individual replacement procedures: see section 7 Replacing
consumables and expendables, page 225.
Proceed as follows:
