Olivetti PR2 E - Page 141

Service ManualY100250-4 9-17
Fig. 9-17
- Remove bushing (4) from alignment pressure roller shaft (5) and then remove the entire
assembly (6).
- Remove the six screws (7) that secure the conveyor assembly (8).
Fig. 9-18
4
6
5
7
7
8
