Omron CP1E Series User Manual

Appendices
A-42
CP1E CPU Unit Hardware User’s Manual(W479)
A-5 Expansion Specifications of External
Power Supply
When using the external power supply for AC-power-supply CPU Units, the external power supply for
the 30-point and 40-point AC-power-supply CPU Units (CP1E--A) can be used beyond
300mA within the capacity range of the power supply built in the CPU Units.
Calculate the usable capacity of external power supply according to the following example.
z Calculation Example of the Capacity Limit of External Power Supply
• Example 1
• Example 2
CPU Unit
Expansion (I/O) Units
Total Limit1st unit 2nd unit 3rd unit
CP1E-N40DR-A CP1W-DA041 CP1W-DA041 CP1W-DA041
5V 0.21A 0.08A 0.08A 0.08A 0.45A ≤1.2A
24V 0.09A 0.124A 0.124A 0.124A 0.462A ≤0.7A
Power
consumption
5V×0.45A=2.25W
24V×0.462A=11.088W
13.338W ≤18.5W
Usable
capacity of
external power
supply
18.5W(Total of usable power consumption)−13.338W=5.162W
5.162W/24V=0.215A
0.215A ≤0.7A
CPU Unit Expansion (I/O) Units
Total Limit1st unit 2nd unit 3rd unit
CP1E-N40DR-A CP1W-20EDT None None
5V 0.21A 0.130A 0.0A 0.0A 0.34A ≤1.2A
24V 0.09A 0.0A 0.0A 0.0A 0.09A ≤0.7A
Power
consumption
5V×0.34A=1.70W
24V×0.09A=2.16W
3.86W ≤18.5W
Usable
capacity of
external power
supply
18.5W(Total of usable power consumption)−3.86W=14.64W
14.64W/24V=0.610A
0.610A ≤0.7A

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
