Omron CP1E Series User Manual

2 Basic System Configuration and Devices
2-12
CP1E CPU Unit Hardware User’s Manual(W479)
Expansion Units and Expansion I/O Units can be connected to the CP1E.
Up to three Expansion Units or Expansion I/O Units can be connected to a CPU Unit with 30 or 40 I/O
points.
Expansion Units and Expansion I/O Units cannot be connected to a CPU Unit with 20 I/O Points.
z Expansion Units
z Expansion I/O Units
2-3-5 I/O Allocation to Expansion Units and Expansion I/O Units
Number of I/O Words
Unit name Model
I/O words
Input Output
Analog Input Unit CP1W-AD041 4 (CIO m to m+3) 2 (CIO n to n+1)
Analog Output Unit CP1W-DA041 − 4 (CIO n to n+3)
Analog I/O Unit CP1W-MAD11 2 (CIO m to m+1) 1 (CIO n)
Temperature Sensor Units CP1W-TS001 2 (CIO m to m+1) −
CP1W-TS101
CP1W-TS002 4 (CIO m to m+3) −
CP1W-TS102
CompoBus/S I/O Link Unit CP1W-SRT21 1 (CIO m) 1 (CIO n)
Unit name Model
I/O words
Input Output
8-point Input Unit CP1W-8ED 1 (CIO m)
-
8-point Output Units CP1W-8ER − 1 (CIO n)
CP1W-8ET
CP1W-8ET1
16-point Output Units CP1W-16ER − 2 (CIO n to n+1)
CP1W-16ET
CP1W-16ET1
20-point I/O Units CP1W-20EDR1 1 (CIO m) 1 (CIO n)
CP1W-20EDT
CP1W-20EDT1
32-point Output Units CP1W-32ER − 4 (CIO n to n+3)
CP1W-32ET
CP1W-32ET1
40-point I/O Units CP1W-40EDR 2 (CIO m to m+1) 2 (CIO n to n+1)
CP1W-40EDT
CP1W-40EDT1

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
