1 Overview and Specifications
1-10
CP1E CPU Unit Hardware User’s Manual(W479)
1-3 Specifications
The following table lists the general specifications of CP1E CPU Units.
*1 Total of 110 mm with mounting brackets.
*2 Excluding cables.
1-3-1 General Specifications
Item AC power supply DC power supply
Model CP1E--A CP1E-N-D
Enclosure Mounted in a panel
Dimensions (H × D × W)
CPU Unit with 20 I/O points (CP1E-20D-) : 90mm*
1
×85mm*
2
×86mm
CPU Unit with 30 I/O points (CP1E-30D-) : 90mm*
1
×85mm*
2
×130mm
CPU Unit with 40 I/O points (CP1E-40D-) : 90mm*
1
×85mm*
2
×150mm
Weight CPU Unit with 20 I/O points (CP1E-20D-) : 370g max.
CPU Unit with 30 I/O points (CP1E-30D-) : 600g max.
CPU Unit with 40 I/O points (CP1E-40D-) : 660g max.
Electri-
cal spec-
ifications
Supply voltage 100 to 240 VAC 50/60 Hz 24 VDC
Operating voltage range 85 to 264 VAC 20.4 to 26.4 VDC
Power consumption 15 VA /100 VAC max.
25 VA /240 VAC max.
(CP1E-20D-A) 13W max. (CP1E-20D-D)
50 VA /100 VAC max.
70 VA /240 VAC max.
(CP1E-30D-A/40D-A) 34W max. (CP1E-30D-D/40D-D)
Inrush current 120 VAC, 20 A for 8 ms max. for cold start at room tem-
perature
240 VAC, 40 A for 8 ms max. for cold start at room tem-
perature
30A for 20 ms max. for cold start at room temperature
External power supply Not provided. (CP1E-20D-A)
24 VDC, 300 mA (CP1E-30D-A/40D-A)
Not provided.
Insulation resistance 20 MΩ min. (at 500 VDC) between the external AC ter-
minals and GR terminals
Except between DC primary current and DC secondary
carrent
Dielectric strength 2,300 VAC 50/60Hz for 1 min between AC external and
GR terminals Leakage current: 5 mA max.
Except between DC primary current and DC secondary
carrent
Power interrupt time 10 ms min. 2 ms min.
Applica-
tion envi-
ronment
Ambient operating temper-
ature
0 to 55°C
Ambient humidity 10% to 90%
Atmosphere No corrosive gas.
Ambient storage tempera-
ture
-20 to 75°C (excluding battery)
Altitude 2,000 m max.
Pollution degree 2 or less: Conforms to JIS B3502 and IEC 61131-2.
Noise resistance 2 kV on power supply line (Conforms to IEC61000-4-4.)
Overvoltage category Category II: Conforms to JIS B3502 and IEC 61131-2.
EMC immunity level Zone B
Vibration resistance Conforms to JIS 60068-2-6.
5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz
Acceleration of 9.8 m/s
2
for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total)
Shock resistance Conforms to JIS 60068-2-27.
147 m/s
2
, 3 times in X, Y, and Z directions
Terminal block Fixed (not removable)
Terminal screw size
M3
Applicable standards Conforms to EC Directives.
Grounding method Ground to 100Ω or less.
