Omron CP1E Series User Manual

4-3
4 Programming Device
CP1E CPU Unit Hardware User’s Manual(W479)
4-1 CX-Programmer for CP1E
4
4-1-2 CX-Programmer for CP1E
The CX-Programmer for CP1E is a basic software application for creating and debugging PLC pro-
grams.
The following system is required to operate the CX-Programmer for CP1E. Make sure your system pro-
vides the following conditions and has the necessary components.
• With two menu levels, menu commands can be easily found.
• Options have been simplified.
4-1-2 CX-Programmer for CP1E
CX-Programmer for CP1E
4-1-3 Operating Environment and System Configuration
Item Description
Supported computer IBM PC/AT or equivalent
CD-ROM or DVD-ROM drive One or more
Supported operating systems Windows Vista, Windows XP, Windows 2000 (Service
Pack 2 or later)
CPU Pentium II 333 MHz or faster
RAM 256 MB min., 512 MB or more recommended
Required hard disk space 600 MB min.
Display 800 x 600 SVGA min.
PLC and connection port USB port
Supported PLCs CP1E
4-1-4 Features of the CX-Programmer for CP1E
Simple Menu Configuration
CX-Programmer
for CP1E
Programming Tasks Ladder diagrams
Programming functions
Simulation
Monitoring
Debugging and maintenance functions
PLC Setup
CPU Unit parameters

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
