Omron CP1E Series User Manual

2-15
2 Basic System Configuration and Devices
CP1E CPU Unit Hardware User’s Manual(W479)
2-4 Unit Current Consumption and External
Power Supply Capacity
2
2-4-1 External Power Supply Capacity When Expansion I/O Units or Expansion Units are Connected
2-4 Unit Current Consumption and
External Power Supply Capacity
This section describes the current consumption and external power supply capacity of units used by the
CP1E.
Power of 24 VDC can be supplied to external devices from CPU Units with 30 or 40 I/O points.
Calculate the usable capacity of external power supply according to the following example.
2-4-1 External Power Supply Capacity When Expansion I/O Units or
Expansion Units are Connected
Calculation Examples of the Capacity Limit of External Power
Supply
CPU Unit Expansion Units Total Limit
1
st
unit 2
nd
unit 3
rd
unit
CP1E-40D-A CP1W-
DA041
CP1W-
DA041
CP1W-
DA041
5V 0.21A 0.08A 0.08A 0.08A 0.45A ≤1.2A
24V 0.09A 0.124A 0.124A 0.124A 0.462A ≤0.7A
Power consump-
tion
5 V×0.45 A=2.25 W
24 V×0.462 A=11.088 W
13.388 W ≤18.5 W
Usable capacity of
external power
supply
18.5 W (Total of usable power consumption) − 13.388 W=
5.162 W
5.162 W/24 V=0.215 A
0.215A ≤0.3A

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
