Omron CP1E Series User Manual

2
CP1E CPU Unit Hardware User’s Manual(W479)
CS Series
CS1-H CPU Units
CS1H-CPUH
CS1G-CPUH
CS1 CPU Units
CS1H-CPU(-V1)
CS1G-CPU(-V1)
CS1D CPU Units
CS1D CPU Units for
Duplex-CPU System
CS1D-CPU
H
CS1D CPU Units for
Single-CPU System
CS1D-CPU
S
CS1D Process CPU Units
CS1D-CPU
P
CS-series Basic I/O Units
CS-series Special I/O Units
CS-series CPU Bus Units
CS-series Power Supply Units
Note: Products specifically for the CS1D
Series are required to use CS1D
CS/CJ/CP Series
CJ Series
CJ1-H CPU Units
CJ1H-CPUH
CJ1G-CPUH
CJ1G-CPUP
(Loop CPU Unit)
CJ1M CPU Unit
CJ1M-CPU
CJ1 CPU Unit
CJ1G-CPU
CJ-series Basic I/O Units
CJ-series Special I/O Units
CJ-series CPU Bus Units
CJ-series Power Supply Units
CP Series
CJ-series Special I/O Units*
CJ-series CPU Bus Units*
CP-series Expansion I/O Units
CP-series Expansion Units
* Can only be used for CP1H
CPU Units.
CP1H-XD-
CP1H-XAD-
CP1H-YDT-D
CP1H CPU Units
CP1L-MD-
CP1L-LD-
CP1E CPU Units
CP1E-ED-A
CP1E-ND-
CP1L CPU Units

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
