154
IR Area Section 3-2
I/O Words Required by
Dedicated I/O Units
Note A total of 5 words are required when the next 4 Modules (E3X-MA11, E3C-
MA11, E2C-MA11, and E39-M11) are mounted.
Name Model Input words
(starting from
IR 001)
Output words
(starting from
IR 100)
Analog Input Unit CQM1-AD041 2 or 4 ---
Analog Output Units CQM1-DA021 --- 2
Power Supply Units CQM1-IPS01 --- ---
CQM1-IPS02
B7A Interface Units CQM1-B7A02 --- 1
CQM1-B7A12 1 ---
CQM1-B7A03 --- 2
CQM1-B7A13 2 ---
CQM1-B7A21 1 1
G730 Interface Units CQM1-G7M21 2 or 1 2 or 1
CQM1-G7N11 2 or 1 ---
CQM1-G7N01 --- 2 or 1
I/O Link Unit CQM1-LK501 2 2
Sensor Units CQM1-SEN01 1 (See note.) ---
Optical Fiber
Photoelectric Module
E3X-MA11 1 ---
Photoelectric Module with
Separate Amplifier
E3C-MA11 1
Proximity Module with
Separate Amplifier
E2C-MA11 1
Dummy Module E39-M11 1
Remote Console CQM1-TU001 ---
Temperature Control Units CQM1-TC001 2 or 1 2 or 1
CQM1-TC002
CQM1-TC101
CQM1-TC102
CQM1-TC201 1 1
CQM1-TC202 1 1
CQM1-TC203 1 1
CQM1-TC204 1 1
CQM1-TC301 1 1
CQM1-TC302 1 1
CQM1-TC303 1 1
CQM1-TC304 1 1
Linear Sensor Interface
Units
CQM1-LSE01 1 1
CQM1-LSE02 1 1
CompoBus/S Master Unit CQM1-SRM21-V1 4, 2, or 1 4, 2, or 1
CompoBus/D I/O Link Unit CQM1-DRT21 1 1

Omron CQM1H - PROGRAM Specifications

General

I/O Capacity	Up to 512 points
Power Supply	100 to 240 VAC, 50/60 Hz or 24 VDC (depending on model)
Instruction Set	Basic and advanced instructions
Operating Temperature	0 to 55°C
Program Capacity	7.2K to 15.2K steps
Communication Ports	RS-232C
Expansion Slots	Up to 3 expansion units
Type	Programmable Logic Controller (PLC)
CPU Type	RISC
Program Memory	7.2K to 15.2K steps
I/O Points	512 max
Expansion Capability	Up to 3 expansion units
Data Memory	RAM (battery backup)
