Omron CQM1H - PROGRAM User Manual

153
IR Area Section 3-2
I/O Words Required
by I/O Units
Name I/O
points
Model Input words
(starting from
IR 001)
Output words
(starting from
IR 100)
DC Input
Units
8 CQM1-ID211 1 ---
16 CQM1-ID111 1
CQM1-ID212 1
32 CQM1-ID112 2
CQM1-ID213 2
CQM1-ID214 2
AC Input
Units
8 CQM1-IA121 1
CQM1-IA221 1
Relay
Output
Units
8 CQM1-OC221 --- 1
16 CQM1-OC222 1
CQM1-OC224 1
Transistor
Output
Units
8 CQM1-OD211 1
16 CQM1-OD212 1
32 CQM1-OD213 2
CQM1-OD216 2
16 CQM1-OD214 1
8 CQM1-OD215 1
AC Output
Units
8 CQM1-OA221 1
6 CQM1-OA222 1

Omron CQM1H - PROGRAM Specifications

General

I/O Capacity	Up to 512 points
Power Supply	100 to 240 VAC, 50/60 Hz or 24 VDC (depending on model)
Instruction Set	Basic and advanced instructions
Operating Temperature	0 to 55°C
Program Capacity	7.2K to 15.2K steps
Communication Ports	RS-232C
Expansion Slots	Up to 3 expansion units
Type	Programmable Logic Controller (PLC)
CPU Type	RISC
Program Memory	7.2K to 15.2K steps
I/O Points	512 max
Expansion Capability	Up to 3 expansion units
Data Memory	RAM (battery backup)
