Omron CQM1H - PROGRAM User Manual

482
Cycle Time Section 7-3
35 ORW 31.5 Constant V word → word 1.875
33.9 Word V word → word
85.6 *DM V *DM → *DM
36 XORW 31.5 Constant V
word → word 1.875
33.9 Word V word → word
85.6 *DM V
*DM → *DM
37 XNRW 31.5
Constant V word → word
1.875
33.9
Word V
word → word
85.6
*DM V *DM → *DM
38 INC 20.9 When incrementing a word 1.125
37.6 When incrementing *DM
39 DEC 21.3 When decrementing a word 1.125
38.1 When decrementing *DM
40 STC 9.0 Any 0.75
41 CLC 9.0 0.75
45 TRSM 21.6 0.75
46 MSG 18.5 With message in words 1.125
36.3 With message in *DM
50 ADB 40.1 Constant + word → word 1.875
42.5 Word + word → word
94.2 *DM + *DM → *DM
51 SBB 40.1 Constant – word → word 1.875
42.5 Word – word → word
94.2 *DM – *DM → *DM
52 MLB 34.3 Constant × word → word 1.875
36.7 Word × word → word
87.3 *DM × *DM → *DM
53 DVB 35.1 Word ÷ constant → word 1.875
37.5 Word ÷ word → word
88.1 *DM ÷ *DM → *DM
54 ADDL 44.5 Word + word → word 1.875
96.7 *DM + *DM → *DM
55 SUBL 44.5 Word – word → word 1.875
96.7 *DM – *DM → *DM
56 MULL 153.4 Word × word → word 1.875
203.4 *DM × *DM → *DM
57 DIVL 154.5 Word ÷ word → word 1.875
204.5 *DM ÷ *DM → *DM
58 BINL 57.0 Word → word 1.5
90.5 *DM → *DM
59 BCDL 45.7 Word → word 1.5
79.2 *DM → *DM
70 XFER 54.7 When transferring a constant to a word 1.875
57.1 When transferring a word to a word
2.2 ms When transferring 1,024 words using *DM
12.5 ms When transferring 6,144 words using *DM
71 BSET 34.2 When setting a constant to 1 word 1.875
58.5 When setting word constant to 10 words
1.47 ms When setting *DM to 1,024 words
8.22 ms When setting *DM to 6,144 words
Code Mnemonic ON execution
time (µs)
Conditions (Top: min.; bottom: max.) OFF execution time (µs)
