Omron CQM1H - PROGRAM

483
Cycle Time Section 7-3
72 ROOT 48.0 Word calculation → word 1.5
83.1 *DM calculation → *DM
73 XCHG 30.7 Word → word 1.5
64.2 *DM → *DM
74 SLD 30.9 Shifting 1 word 1.5
76.5 Shifting 10 word
4.12 ms Shifting 1024 words using *DM
24.44 ms Shifting 6144 words using *DM
75 SRD 30.9 Shifting 1 word 1.5
76.5 Shifting 10 word
4.12 ms Shifting 1,024 words using *DM
24.44 ms Shifting 6,144 words using *DM
76 MLPX 44.4 When decoding word to word 1.875
102.3 When decoding *DM to *DM
77 DMPX 33.9 When encoding word to word 1.875
90.5 When encoding *DM to *DM
78 SDEC 45.5 When decoding word to word 1.875
103.9 When decoding *DM to *DM
80 DIST 49.5 When setting a constant to a word + a word 1.875
52.0 When setting a word to a word + a word
108.3 When setting *DM to *DM +*DM
75.8 When setting a constant to a stack
78.3 When setting a word to a stack
133.4 When setting *DM to a stack via *DM
81 COLL 48.9 When setting a constant + a word to a word 1.875
51.3 When setting a word + a word to a word
105.1 When setting *DM + *DM to *DM
45.9 When setting a word + constant to FIFO stack
48.3 When setting a word + word to FIFO stack
103.2 When setting a *DM + *DM to
FIFO stack via *DM
45.3 When setting a word + constant to LIFO stack
47.7 When setting a word + word to LIFO stack
102.6 When setting a *DM + *DM to
LIFO stack via *DM
82 MOVB 34.8 When moving constant to word 1.875
41.2 When moving word to word
93.9 When moving *DM to *DM
83 MOVD 30.6 When moving constant to word 1.875
36.9 When moving word to word
89.6 When moving *DM to *DM
84 SFTR 43.1 Shifting 1 word 1.875
73.8 Shifting 10 word
1.7 ms Shifting 1,024 words using *DM
9.68 ms Shifting 6,144 words using *DM
85 TCMP 71.9 Comparing constant to word-set table 1.875
74.1 Comparing word to word-set table
126.8 Comparing *DM to *DM-set table
86 ASC 46.9 Word → word 1.875
108.3 *DM → *DM
Code Mnemonic ON execution
time (µs)
Conditions (Top: min.; bottom: max.) OFF execution time (µs)
