Omron CQM1H - PROGRAM - Page 515

490
Cycle Time Section 7-3
–– HMS 73.9 Word → word 1.875
114.3 *DM → *DM
–– LINE 72.8 Word → word 1.875
127.6 *DM → *DM
–– LOG 552.0 Word → word 1.875
586.0 *DM → *DM
–– MAX 44.8 Searching word, results to word 1.875
1.93 ms Searching 999 words via *DM, results to *DM
–– MBS 46.2 Constant × word → word 1.875
48.6 Word × word → word
104.0 *DM × *DM → *DM
–– MBSL 73.2 Word × word → word 1.875
128.4 *DM × *DM → *DM
–– MIN 44.8 Searching word, results to word 1.875
1.33 ms Searching 999 words via *DM, results to *DM
–– NEG 33.7 Converting a constant → word 1.875
36.1 Converting a word → word
72.3 Converting *DM → *DM
–– NEGL 41.1 Converting a constant → words 1.875
80.1 Converting *DM → *DM
–– PID 1.59 ms Word → word (initial execution) 1.875
1.73 ms *DM → *DM (initial execution)
458.5 Word → word (when sampling)
673.0 *DM → *DM (when sampling)
–– PLS2 619.0 Words for control words 1.875
639.8 *DM for control words
–– PMCR 182.0 Constant for port/sequence number, DM for I/O word 1.875
728.0 *DM for port/sequence number, *DM for I/O word
772.0 *DM for port/sequence number, *DM for I/O word
–– PWM 202.8 Duty ratio specified by constant 1.875
207.4 Duty ratio specified by word
223.1 Duty ratio specified by *DM
–– RAD 106.0 Word → word 1.875
140.4 *DM → *DM
–– SBBL 59.3 Word – word → word 1.875
116.7 *DM – *DM → *DM
–– SCL2 81.5 Word → word conversion, words for parameter words 1.875
137.6 *DM → *DM conversion, *DM for parameter words
–– SCL3 86.7 Word → word conversion, words for parameter words 1.875
142.8 *DM → *DM conversion, *DM for parameter words
–– SEC 72.4 Word → word 1.875
112.4 *DM → *DM
–– SIN 716.0 Word → word 1.875
750.0 *DM → *DM
–– SQRT 206.0 Word → word
*DM → *DM
Code Mnemonic ON execution
time (µs)
Conditions OFF execution
time (µs)
