Omron E5ZN - Multi-SP Uses (Mspu); SP Ramp Set Value (Sprt)

155
Advanced Function Setting Level Section 7-6
Settings
Note The relationship with the external signal when RUN/STOP has been selected is shown
below.
External signal OFF: STOP (operation stop)
ON: RUN (operation)
See Also • Related Parameter
“Number of Multi-SP uses” (advanced function setting level) (page 154)
7-6-4 Multi-SP Uses (mspu)
Condition: The “number of multi-SP uses” parameter must be set to 0.
Function • When set to ON, this parameter enables switching between SP0 and SP1
by using communications command or E5ZN-SDL Setting Display Unit
key operations.
• Setting changes to this parameter must be enabled by executing a soft-
ware reset or by turning ON the power again.
Communications
Settings
Note To switch between SPs using event input, set the “number of multi-SP uses” to “1.”
See Also • Related Parameter
“Number of Multi-SP uses” (advanced function setting level) (page 154)
7-6-5 SP Ramp Set Value (sprt)
Function • This parameter specifies the rate of change during SP ramp operation.
Set the maximum permissible change width per unit of time (minute) as
the “SP ramp set value.” When the “SP ramp set value” is set to 0, the SP
ramp function is disabled.
• During temperature input, the decimal point position of the SP ramp set
value is dependent on the currently selected sensor, and during analog
input it is dependent on scaling.
• Setting changes to “SP ramp set value” must be enabled by executing a
software reset or by turning ON the power again.
Setting range Unit Default
00000000H to 00000001H
0: None (none)
1: RUN/STOP (stop)
- 0: None
ch Variable type Address
Shared C3 0019 or 0119
Setting range Unit Default
00000000H to 00000001H
0: OFF (off)
1: ON (on)
-0: OFF
