Initial Setting Level Section 7-5
Settings
See Also
3-4 Setting Output Specifications (page 25)
7-5-8 Alarm 1 Type (alt1)
Alarm 2 Type (alt2)
Alarm 3 Type (alt3)
Function These parameters select alarm type for alarms 1, 2, or 3
Communications
Settings
See Also
• Related Parameters
“Alarm 1 to 3 value” (operation level) (page 131)
“Upper limit alarm value 1” “Lower limit alarm value 1” (operation level)
(page 132) “Upper limit alarm value 2” “Lower limit alarm value 2” (opera-
tion level) (page 133)
“Standby sequence reset” (advanced function setting level) (page 156)
“Alarm 1 to 3 open in alarm” (advanced function setting level) (page 157)
“Alarm 1 to 3 hysteresis” (advanced function setting level) (page 158)
“Alarm 1 to 3 latch” (advanced function setting level) (page 163)
7-5-9 Control Output 1 Allocation (out1)
Function This function assigns the data to be output to the control output 1 terminals
(terminals 7 and 8.)
Settings range Unit Default
00000000H to00000001H
0: Reverse operation (or-r)
1: Direct operation (or-d)
-0: Reverse
operation
Setting ch Variable type Address
Alarm 1 type 1 C3 000B
2 C3 010B
Alarm 2 type 1 C3 000C
2 C3 010C
Alarm 3 type 1 C3 000D
2 C3 010D
Setting Settings range Unit Default
Alarm 1 type
Alarm 2 type
Alarm 3 type
00000000H (0): No alarm function
00000001H (1): Upper and lower limit alarm
00000002H (2): Upper limit alarm
00000003H (3): Lower limit alarm
00000004H (4): Upper and lower limit range alarm
00000005H (5): Upper and lower limit alarm with standby sequence
00000006H (6): Upper limit alarm with standby sequence
00000007H (7): Lower limit alarm with standby sequence
00000008H (8): Absolute value upper limit alarm
00000009H (9): Absolute value lower limit alarm
0000000AH (10): Absolute value upper limit alarm with standby sequence
0000000BH (11): Absolute value lower limit alarm with standby sequence
- 2: Upper limit
alarm
