Examples and tips
PROGRAMMING MANUAL 237
Revision 3.0
/i
Example 2
fig. 14
The Following Error reduces as the rigidity increases.
The parameter values for the example are:
/i
Example 3
fig. 15
With high gain the motor starts to vibrate but the profile is more
stable that in MECHATROLINK-II Speed mode.
The parameter values for the example are:
/i
Motion Parameter values
Fn001=4
Pn109=0
Motion Parameter values
Fn001=6
Pn109=0
Motion Parameter values
Fn001=8
Pn109=0
