7-4 Auto Focus Multi Code Reader V430-series User’s Manual (Z392)
I/O Parameters Serial Commands
ISO/IEC 15415 Symbol Quality Output 1
< K870 , Output on Overall Grade, Overall Grade Threshold, Symbol
Contrast, Symbol Contrast Threshold, Modulation, Modulation
Threshold, Reflectance Margin, Reflectance Margin Threshold,
Fixed Pattern Damage, Fixed Pattern Damage Threshold, Axial Non-
uniformity, Axial Nonuniformity Threshold, Grid Nonuniformity, Grid
Nonuniformity Threshold, Unused ECC, Unused ECC Threshold>
ISO/IEC 15415 Symbol Quality Output 2
< K871 , Output on Overall Grade, Overall Grade Threshold, Sym-
bol Contrast, Symbol Contrast Threshold, Modulation, Modulation
Threshold, Reflectance Margin, Reflectance Margin Threshold,
Fixed Pattern Damage, Fixed Pattern Damage Threshold, Axial
Nonuniformity, Axial Nonuniformity Threshold, Grid Nonuniformity,
Grid Nonuniformity Threshold, Unused ECC, Unused ECC
Threshold>
ISO/IEC 15415 Symbol Quality Output 3
< K872 , Output on Overall Grade, Overall Grade Threshold, Sym-
bol Contrast, Symbol Contrast Threshold, Modulation, Modulation
Threshold, Reflectance Margin, Reflectance Margin Threshold,
Fixed Pattern Damage, Fixed Pattern Damage Threshold, Axial
Nonuniformity, Axial Nonuniformity Threshold, Grid Nonuniformity,
Grid Nonuniformity Threshold, Unused ECC, Unused ECC
Threshold>
ISO/IEC 15416 Symbol Quality Output 1
< K880 , Output on Overall Grade, Overall Grade Threshold, Edge
Determination, Edge Determination Threshold, Decode, Decode
Threshold, Contrast, Contrast Threshold, Min Reflectance, Min
Reflectance Threshold, Min Edge Contrast, Min Edge Contrast
Threshold, Modulation, Modulation Threshold, Defects, Defects
Threshold, Decodability, Decodability Threshold, Quiet Zone,
Quiet Zone Threshold >
ISO/IEC 15416 Symbol Quality Output 2
< K881 , Output on Overall Grade, Overall Grade Threshold, Edge
Determination, Edge Determination Threshold, Decode, Decode
Threshold, Contrast, Contrast Threshold, Min Reflectance, Min
Reflectance Threshold, Min Edge Contrast, Min Edge Contrast
Threshold, Modulation, Modulation Threshold, Defects, Defects
Threshold, Decodability, Decodability Threshold, Quiet Zone,
Quiet Zone Threshold >
ISO/IEC 15416 Symbol Quality Output 3
< K882 , Output on Overall Grade, Overall Grade Threshold, Edge
Determination, Edge Determination Threshold, Decode, Decode
Threshold, Contrast, Contrast Threshold, Min Reflectance, Min
Reflectance Threshold, Min Edge Contrast, Min Edge Contrast
Threshold, Modulation, Modulation Threshold, Defects, Defects
Threshold, Decodability, Decodability Threshold, Quiet Zone,
Quiet Zone Threshold >
ISO/IEC 29158 Symbol Quality Output 1
< K890 , Output on Overall Grade, Overall Grade Threshold, Cell
Contrast, Cell Contrast Threshold, Cell Modulation, Cell Modula-
tion Threshold, Fixed Pattern Damage, Fixed Pattern Damage
Threshold, Axial Nonuniformity, Axial Nonuniformity Threshold,
Grid Nonuniformity, Grid Nonuniformity Threshold, Unused ECC,
Unused ECC Threshold>
ISO/IEC 29158 Symbol Quality Output 2
< K891 , Output on Overall Grade, Overall Grade Threshold, Cell
Contrast, Cell Contrast Threshold, Cell Modulation, Cell Modula-
tion Threshold, Fixed Pattern Damage, Fixed Pattern Damage
Threshold, Axial Nonuniformity, Axial Nonuniformity Threshold,
Grid Nonuniformity, Grid Nonuniformity Threshold, Unused ECC,
Unused ECC Threshold>
ISO/IEC 29158 Symbol Quality Output 3
< K892 , Output on Overall Grade, Overall Grade Threshold, Cell
Contrast, Cell Contrast Threshold, Cell Modulation, Cell Modula-
tion Threshold, Fixed Pattern Damage, Fixed Pattern Damage
Threshold, Axial Nonuniformity, Axial Nonuniformity Threshold,
Grid Nonuniformity, Grid Nonuniformity Threshold, Unused ECC,
Unused ECC Threshold>
