Auto Focus Multi Code Reader V430-series User’s Manual (Z392) 7-3
I/O Parameters
I/O Parameters Serial Commands
Power On/Reset Counts
<K406,power-on,resets,power-on saves,customer default saves>
Time Since Reset (Read-Only)
<K407,hours,minutes>
Service Message
<K409,status,service message,threshold,resolution>
User-Defined Name
<K412,user-defined name>
Serial Verification
<K701,serial command echo status,control/hex output>
Quality Output
<K704,quality output separator,decodes per trigger status>
Symbol Data Output
<K705,status,when to output,symbology identifier status>
Read Duration Output
<K706,status,separator>
No-Read Message
<K714,status,message>
Output Object Info
<K734,output frame number status,output coordinates status>
LED Configuration
<K737,ISO/IEC 16022 grade>
Output Indicators
<K750,green flash LED status,target pattern LED status,green
flash duration>
EZ Trax Output
<K757,EZ Trax Enable,Transfer Port,EZ Trax Image Mode,Image
Format,Image Quality,Object Info Enable,Grade Enable>
Database Identifier Output
<K759,status,separator character>
Image Push to Host
< K764 , Image Storage Status,Stored Image Type,Image Storage,
Image File Format,Image Quality,Image Scale,File Save Options>
Image Push to Host Detail Setup
< K763, Image Storage Location,FTP Host Info,Transfer Optimization,
RAM Drive Size in MB,Save Image Until,Action at Image Storage Limit>
Setup Button
< K770, global status,default on power-on,load configuration database,
save for power-on>
Setup Button Modes
< K771, button option 1,button option 2,button option 3,button option 4>
Trend Analysis Output 1
<K780,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
Trend Analysis Output 2
<K781,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
Trend Analysis Output 3
<K782,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
Diagnostic Output 1
<K790,service unit message status>
Diagnostic Output 2
<K791,service unit message status>
Diagnostic Output 3
<K792,service unit message status>
ISO/IEC 16022 Symbol Quality Output 1
< K800, output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity ,
axial non-uniformity threshold,output on Unused ECC,Unused ECC
threshold>
ISO/IEC 16022 Symbol Quality Output 2
< K801, output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity ,
axial non-uniformity threshold,output on Unused ECC,Unused ECC
threshold>
ISO/IEC 16022 Symbol Quality Output 3
< K802, output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity ,
axial non-uniformity threshold,output on Unused ECC,Unused ECC
threshold>
Output 1 Parameters
<K810,output on,output state,pulse width,output mode>
Output 2 Parameters
<K811,output on,output state,pulse width,output mode>
Output 3 Parameters
<K812,output on,output state,pulse width,output mode>
