13-10 Auto Focus Multi Code Reader V430-series User’s Manual (Z392)
Master Database
Master Database
Important: The Master Database is used for all Matchcode modes except Sequential
and Wild Card, both of which use Master Database Index # 1.
Master Database Overview
Used where more than one master symbol is required, as in a Multisymbol setup, for
matching and other Matchcode operations.
Allows the user to define up to 10 master symbols as the master symbol database, which
can be entered by keyboard, scanned in, displayed, or deleted by serial or ESP commands.
1. Click the Master Database tab.
2. Enable Matchcode Type.
3. Set the Master Symbol Database Size.
4. Select the database index in which the master symbol will be entered.
5. Do one of the following to enter master symbol data:
a. Double-click the index row to type data directly into the index.
b. Click the Read Symbol into Selected Index to enter the next decoded symbol.
Click the Utilities button and then the Master Database
tab to display the Master Database view.
Set Master Symbol
Database Size here.
Loads the reader’s saved
master symbols into ESP.
Double-click a row to enter data into popup text box.
Loads the next symbol decoded
into the selected index.
Saves the
database to
the reader.
