A-2 Auto Focus Multi Code Reader V430-series User’s Manual (Z392)
General Specifications
Appendix A — General Specifications
Model V430-F00050C V430-F00012M V430-FM03M
Applicable codes
*1
Bar code
Code 39, Code 128, BC412, ITF (Interleaved 2 of 5), EAN/UPC,
Codabar, Code 93, Pharmacode, PLANET, POSTNET, Japanese
Post, Australian Post, Royal Mail, Intelligent Mail, KIX, UPU, GS1
Databar (Composite)
2D code
DataMatrix (ECC000-ECC200), QR Code, Micro QR Code, Aztec
Code, DotCode, PDF417, Micro PDF417, GS1 Databar (Stacked)
Reading perfor-
mance
*2
Number of
reading digits
No upper limit (depends on bar width and reading distance)
Aiming light Two Blue LEDs
Light source
• Inner LEDs: Four White and Four Red LEDs (wave length: 625 nm)
• Outer LEDs:
Eight White LEDs
• Outer LEDs:
Eight Red LEDs
(wave length: 617 nm)
• Outer LEDs:
Eight Red LEDs
(wave length: 617 nm)
Installation
distance
*3
Field of view
*3
Pitch angle
(α)
±30°
Skew angle
(β)
±30°
Tilt angle (γ) ±180°
Image capture
device
Effective
pixels
2592 (H) x 1944 (V) 1280 (H) x 960 (V) 752 (H) x 480 (V)
Color/
Monochrome
Color CMOS Monochrome CMOS Monochrome CMOS
Shutter
Method
Rolling shutter Global shutter Global shutter
Frame Rate 5 fps 42 fps 60 fps
Shutter Speed 50 us to 100 ms
Image logging FTP
Reading trigger
External trigger (edge, level), Trigger by command (Ethernet, RS-
232C)
I/O specifications
Input signals Trigger, New Master: 4.5 to 28V rated (10 mA at 28 VDC)
Output signals
Output1, Output2, Output3: 1 to 28V rated
(100 mA Max. at 24 VDC)
Communica-
tion specifica-
tion
RS-232C, Ethernet TCP/IP
Ethernet
specifications
100BASE-TX/10BASE-T
