Auto Focus Multi Code Reader V430-series User’s Manual (Z392) A-3
Appendices
*1. These are the code types supported based on Omron’s read capability validation standard. It is recom-
mended that the customer do its own validation in its actual work environment.
*2. Unless otherwise specified, the reading performance is defined with center of field of view, angle R=∞.
Indicator Lamps
PASS (Green), TRIG (Amber), MODE (Amber), LINK (Amber),
FAIL (Red), PWR (Green)
Power voltage 5.0 to 30.0 VDC (including ripple)
Consumption current 0.18A (typ.) (at 24VDC)
Environmental
specifications
Ambient
temperature
range
Operating: 0 to 40°C, Storage: -50 to +75°C (with no icing or con-
densation)
Ambient
humidity range
Operating: 5 to 95%RH, Storage: 5 to 85%RH (with no condensa-
tion)
Ambient
atmosphere
No corrosive gases
Vibration
Resistance
(destruction)
10 to 55 Hz, double amplitude: 0.35 mm, X/Y/Z directions, 10
cycles/axis
Shock resis-
tance
(destruction)
150 m/s
2
, 3 times in each X/Y/Z directions
Degree of
protection
IEC 60529 IP67
Weight
Main body
only
Approx. 68 g
Packing
weight
Approx. 174 g
Dimensions
Main body
Dimension
44.5 (W) × 44.5 (D) × 25.4 (H) mm
Packing
Dimension
170 (W) × 117 (D) × 86 (H) mm
Accessories Instruction manual("Read me first"), Compliance Sheet (CE)
LED class Risk Group Exempt (IEC 62471-1)
Safety standards
EN61326-1: 2013
FCC Part 15, Subpart B (Class A)
UL60950-1
Material
Case Aluminum diecast, alumite (black)
Reading win-
dow
Acrylic
Model V430-F000îš…50C V430-F000îš…12M V430-Fîš…îš…îš…M03M
