3-12 Auto Focus Multi Code Reader V430-series User’s Manual (Z392)
Ethernet
Search and Configure Mode
Note:
Search is the non-applicable function in V430-F. Please use DDU (Device Discovery
Utility) software, when using V430-F.
Search and Configure Mode
is intended primarily for initial setup of an reader in a network.
This parameter controls whether or not the reader will respond to ESP’s Search function in
the Ethernet TCP/IP connect dialog section of the Connection Wizard:
Changes to this parameter are saved to NOVRAM and are set to default on power on.
A Reset <A> is required for settings to take effect.
Important: Once this setting is Disabled, ESP will only be able to connect to the reader if
you know the IP address and enter it in the IP Address field of the Ethernet TCP/IP connect
dialog. Search and Configure Mode can be re-enabled by defaulting the reader.
Enabled
When enabled, Search and Configure Mode will find the reader and settings can be
changed.
Timed Window
When Timed Window is selected, Search and Configure Mode will find the reader and
settings can be changed, but only 60 seconds from the last reset. After 60 seconds,
Search and Configure Mode will be disabled.
After the reader is in full use in an
application, you may want the
reader to continue to appear in the
Search response list for future
searches. This can help prevent
disruption of the system that may
occur is ESP were to show only
unconfigured units.
