Manual Version e1-4.3.0.ae-R3. Page
ANY INTERRUPTION OF THE EARTH CONNEC
OR OUTSIDE THE E1 SERIES IS LIKELY TO MAKE TH
UNIT DANGEROUS. THE SAFETY EARTH CONNECT
SHOULD FULFILL ALL LOCAL SAFETY REQUIREM
ENSURE THAT THIS IS CHECKED DURING THE PRE-
4.1.6 Gas Requirements
• At a minimum, one cylinder of nitrogen gas containing a minimum of 40 cubic feet of gas must
be available during installation. Utilizing a wall- or bench-mounted support bracket, this cylinder
should be firmly secured to prevent possible damage or explosion of the cylinder and/or
cylinder valve. The customer must also provide a suitable pressure regulator (Matheson MA-18
or equivalent) with a shut-off valve for the process gas supply.
• A source of clean dry air, compressed to 70-100 psi is required for operation of the pneumatic
valves. The customer must provide a suitable pressure regulator with shut-off valve for the CDA
supply.
• One standard cylinder filled with xenon difluoride, (not included with the e1 Series), should also
be available for installation within the system. A schematic of a typical cylinder can be found on
page 23.
3
