4 Assembly; Installation; First operation
4.1 Preparation
4.1.1 General Requirements of the Site
A solid laboratory table capable of accommodating the weight of the e1 Series must be provided. The
table should be flat and rigid, and allow adequate airflow and access around the system.
Normal clean room and/or laboratory environmental conditions are adequate for the system.
WARNING
BECAUSE OF THE WEIGHT OF THE XACTIX E1 SERIES
,
THREE OR MORE PEOPLE ARE REQUI
RED DURING THE
INSTALLATION TO REMOVE THE UNIT F
ROM THE
SHIPPING CONTAINER AND TO POSITION IT IN
TO ITS
FINAL POSITION FOR OPERATION.
4.1.2 Dimensions and Weights
Crated dimensions (W x D x H): 54.5” x 34” x 58.5”
(1385mm x 864mm x 1486mm)
Crated weight: ~600 lb (272 kg)
e1 Series dimensions: See Figure 2.
e1 Series weight: ~200 lb (90 kg)
