Orbotech SPTS Xactix e1 Series - Page 37

Manual Version e1-4.3.0.ae-R3. Page
35
Figure 21. CDA pressure regulator and connection.
Figure 22. Gas box exhaust connection.
CDA
pressure
regulator
CDA inlet
connection
