25.3 Disable control output (H2/B3)
Control outputs can be individually disabled. Disabled output will
stay in (or return to) the normal condition for the output respectively.
Disabled outputs are listed in menu H4/U1 from which it is also
possible to get a print-out.
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H2.
Disable or re-enable
ACCEPT? H2
"A"
Disable zone
ACCEPT? B1
Scroll to menu B3.
Disable control output
ACCEPT? B3
"A"
Disable output control unit: 00 Type: 0
0=Loopunit 1=S 2=R 3=RE 4=ES ACCEPT?
(4=ES not valid in Swedish (SBF) convention)
Write C.U. No. and
press:
"0"=RU4 (2265) or
SU4 (2262 / 2263) or
MIO (3361) or
AOU (3364) or
ASI (3377) or
ASB (3378)
"1"=S0-S3
"2"=R0-R1
"3"=Relay board 1581
"4"=1583 board output
"Extinguishing system".
Press "A" to accept.
"A"
Depending on the
chosen type, 0, 1, 2, 3
resp. 4, the following
will be shown:
Disable 00 0000 control output 0
ACCEPT?
Disable S0
ACCEPT?
Disable R0
ACCEPT?
Disable relay board 0 output 0
ACCEPT?
Disable output for extinguishing system
on 1583 board, CU 00 ACCEPT?
Regarding the AOU
(3364) unit's output 2:
The fire door functions
will not be disabled.
Regarding the ASI
(3377) & ASB (3378)
units: Control output
0=high priority
1=medium priority
2=low priority
Write the data.
Press "A" to accept.
LED "Disablements"
(L8) will light up.
