MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
113
27.4 Activated 2-zone/address dependent
zone/address (H4/U4)
("Two unit dependent" in Win512): When only one zone or one
zone / address (alarm point) is in alarm status
99
, the buzzer (in the
c.i.e.) sounds (0.8 / 5 sec.) and there is a Co-incidence alarm
presentation in the c.i.e. display.
The unit(s) or zone(s) in Co-incidence alarm status is (are) shown in
this menu, from which it is also possible to get a print-out.
Action
Text in display
Comments
Co-incidence alarm detector ZZZ/AA
User definable text message (if progr.)
or
Co-incidence alarm zone ZZZ
User definable text message (if progr.)
One alarm point or zone
has activated a Co-
incidence alarm.
ZZZ = zone number
AA = address
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H4.
Present system status on display and
printer ACCEPT? H4
"A"
Disablement
Printout: (1=yes) U1
Scroll to menu U4.
Activated 2-zone/address dependent
zone/address Printout: (1=yes) U4
Press "1" for an automatic
print-out.
Press "A" for presentation
in the display.
"A"
or
When "A" is pressed, the active zone & address (or zone)
will be shown in the display, e.g:
Co-incidence alarm detector ZZZ/AA
L
or
Co-incidence alarm zone ZZZ
L
This is a list in which you
can scroll. If there are no
"alarms" and if "Return" is
pressed, menu U4 will be
shown again.
"1"
Printing started. To stop printing press
C and 0 simultaneously ACCEPT?
Press "A" and menu U4
will be shown again.
"Return"
Activated 2-zone/address dependent
zone/address Printout: (1=yes) U4
Scroll or press "Return" to
menu H4. Scroll or press
"Return" to log off.
99
When two or more zones or units (zone / addresses), dependent on each
other, are in alarm status at the same time, normal fire alarm will be activated
in the system.
