28.9 Select unit on COM-loop to use for trigging
(H5/A8)
NOTE! This menu is not valid for an EBL512 G3 control unit in a
mixed system.
This function is used by service engineer and by R&D for
troubleshooting.
On the pin
112
respectively you will get a pulse to trig an oscilloscope
etc.
COM loop
Main board 1556, JP2, "upper" pin: Each unit not giving a correct
answer.
Main board 1556, JP2, "lower" pin: A specific unit is being polled.
BS4 loop
Autronica interface board 1584 (in the c.i.e.), BY3, "left" pin: A
specific unit is being polled.
Autronica interface board 1584, BY3, "right" pin: 0 V.
(BS4 board = Autronica interface board 1584)
Action
Text in display
Comments
"Access"
According to chapter
"Access code for service
(H5)", see page 126.
Scroll to menu A8
Select unit on COM-/BS4-loop to use for
trigging ACCEPT? A8
"A"
Select type of loop: 0 (0=COM, 1=BS4)
ACCEPT?
Select type of loop. Press
"A" to accept.
"A"
or
"1", "A"
CU: 00 Loop: 0 Address: 000
ACCEPT?
Write control unit number,
(board number; 0-3), loop
number and address. Press
"A" to accept.
CU 00, BS4-Board 0, Loop: 0, Address: 00
ACCEPT?
"A"
Select type of loop: 0 (0=COM, 1=BS4)
ACCEPT?
Select type of loop. Press
"A" to accept or press
"Return" to menu A8..
"Return"
Select unit on COM-/BS4-loop to use for
trigging ACCEPT? A8
Scroll or press "Return" to
H5. Scroll or press
"Return" to log off.
112
The pin might be removed from the p.c.b.
