25.6 Re-enable control output (H2/B6)
Disabled outputs are listed in menu H4/U1 from which it is also
possible to get a print-out.
When all control outputs have been re-enabled, The LED
"Disablements" (L8) will be turned OFF, if there are no other
disablements in the system.
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H2.
Disable or re-enable
ACCEPT? H2
"A"
Disable zone
ACCEPT? B1
Scroll to menu B6.
Re-enable control output
ACCEPT? B6
"A"
Re-enable control output type: 0
0=Loopunit 1=S 2=R 3=RE 4=ES ACCEPT?
(4=ES not valid in Swedish (SBF) convention)
Press:
"0"=RU4 (2265) or
SU4 (2262 / 2263) or
MIO (3361) or
ASI (3377) or
ASB (3378)
"1"=S0-S3
"2"=R0-R1
"3"=Relay board 1581
"4"=1583 board output
"Extinguishing system".
Press "A" to accept.
"A"
Depending on the
chosen type, 0, 1, 2, 3
resp. 4, the following
will be shown:
Re-enable 00 0000 output 0
ACCEPT? L
Re-enable control unit 00 S0
ACCEPT? L
Re-enable control unit 00 R0
ACCEPT? L
Re-enable control unit 00 relay board 0
output 0 ACCEPT? L
Re-enable output for extinguishing
system on 1583 board, CU 00 ACCEPT? L
If there are no outputs to
re-enable, menu B6 will be
shown again.
L=a list in which you can
scroll.
Regarding the ASI (3377)
& ASB (3378) units:
Output:
0=high priority
1=medium priority
2=low priority
If it's the correct output to
re-enable, press "A" to
accept. If not, scroll or
write the wanted output
and press "A" to accept.
