31.8 Test alarm devices (H8/S7)
The programmable outputs
116
type "Alarm device" can be collectively
activated via this menu (H8/S7), which make it possible to test the
alarm devices.
The test cannot be started if fire alarm is activated in the system.
One or all control units can be selected. When the test starts the alarm
devices will sound for approx. 5 seconds, be silent for approx. 25
seconds, sound for approx. 5 seconds and so on.
117
NOTE! Also disabled (and silenced) alarm devices will be tested.
The test will continue for one hour, is stopped via this menu (H8/S7)
or if a fire alarm is activated in the system.
Action
Text in display
Comments
"Access"
According to chapter
"Access code for
maintenance", see page
141.
Scroll to menu S7.
Test alarm devices
ACCEPT? S7
"A"
Test alarm devices on CU 00? (99 = All)
ACCEPT?
Write a CU no. (or "99"
for all CUs) and press "A"
to accept.
"A"
Test of alarm devices in progress.
End test? ACCEPT?
The test will continue for
one hour if not stopped via
this menu (S7) or if a fire
alarm is activated in the
system. Press "A" to
accept / stop the test.
"A"
Test alarm devices
ACCEPT? S7
Scroll or press "Return" to
return to menu H8. Scroll
or press "Return" to log
off.
116
Including Addressable siren 3377 and Addressable sounder base 3378.
117
The output activation will be continuously (steady). For the alarm
devices 3377 and 3378, the tone with the highest priority level (and type
"alarm device") will be automatically selected.
