31.10 Activate address in alarm mode (H8/S9)
One alarm point (address), not a whole zone, can be set in alarm
status. The built-in LED in the alarm point (detector) will be turned
on to indicate the alarm. Among other applications, this function is
used for installations on ships.
NOTE! All outputs, standard and programmable, which would have
been activated by a real fire alarm from the same alarm point, will be
activated by this manual alarm as well.
Alarm activated via this menu will be automatically reset after one
hour.
Action
Text in display
Comments
"Access"
According to chapter
"Access code for
maintenance", see page
141.
Scroll to menu S9.
Activate address in alarm mode
ACCEPT? S9
"A"
Select zone: 000 address: 00
ACCEPT?
Write the zone and
address.
Select zone: 123 address: 45
ACCEPT?
Press "A" to accept / start
the fire alarm.
"A"
POINT: 123-45 No.: 001
User definable text, if programmed
Normal fire alarm
presentation in the control
unit(s) / FBPs display.
If more alarm points have
to be set in alarm status,
press "Return" to select
another zone - address and
continue as above.
"Return"
Select zone: 000 address: 00
ACCEPT?
Write the zone and
address.
Select zone: 012 address: 34
ACCEPT?
Press "A" to accept / start
the fire alarm.
"A"
POINT: 123-45 LAST: 012-34 No.: 002
User definable text, if programmed
