MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
11
Router or Repeater is the same type of unit (different configuration).
All network programming (configuration) are made with the PC
program "TLON Manager".
2.14 LED
LED (Light Emitting Diode) = Yellow, green or red optical indicator
("lamp").
2.15 External Indicator (LED)
A unit with an LED. Connected to an ASB, CDB or a detector with a
built-in LED. Old installations: Also connected to an ADB.
Lit when the built-in LED is lit.
2.16 Display / LCD
LCD (Liquid Crystal Display) = Display (in the c.i.e. or Display unit)
for presentation of fire alarms, fault messages, etc. Normally 40
alphanumeric characters and backlight.
2.17 Door open (Door / Key switch)
In EBL512 there is a door switch, which is activated when the control
unit door is open. In some other units this door switch is replaced
with a key switch.
The LED "Door open" is indicating "door open" / key switch in
position "open".
2.18 Site Specific Data (SSD)
The SSD is unique for each installation. All alarm points,
presentation numbers, user definable text messages, programmable
outputs, etc. are created in the PC program Win512 and also
downloaded in EBL512 with Win512.
2.19 Software (S/W) / System program
The S/W makes the control unit (the microprocessor) work. It is
factory downloaded but a new version can be downloaded in EBL512
on site.
2.20 Mixed system
EBL512 units (1548 / 1549 / 1550) with software EBL512 version
2.7.x, together with EBL512 G3 units (5000 / 5001) with software
EBL512 G3 United version 2.7.x, in a TLON Network, i.e. a mixed
system.
