MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
92
23 Access
To use the key pad in the control unit (to get access to the menu tree),
it is necessary to logon with an access code for level 2, 3 or 4. See
also chapter "Access levels", page 23.
Open the door in the control unit (= level 1), press the "Access" button
(P8) and continue as follows:
Explanations:
Action (in the table) = use push button / key (e.g. signed "Access").
Text in display (in the table) = what is shown in the alphanumeric
display in the control unit (c.i.e.).
Comments (in the table) = Comments to the text in the "Action" and
"Text in display" columns.
Use "" and "" to scroll between the main menus H1-H10.
Use "A" to accept.
Some main menus have sub menus. Use "" and "" to scroll
between the sub menus (e.g. B1-B9). Use "A" to accept.
NOTE! The menus are circular, i.e. if you scroll with "" and the last
menu is reached, the first menu comes up next.
Quick jump can be used within each menu, e.g. in menu H1 press "6"
for a quick jump to menu H6. "1" and "0" (within 1 sec.) = 10.
Instead of a menu identification (e.g. B1), the letter L can be shown,
which means that it is a List. Use "" and "" to scroll in the list.
Use "" and "" to move the cursor in a menu.
Use "Return" to return from a sub menu to the main menu (H1-H10).
Use "Return" to log off from a main menu (H1-H10).
There will be an automatic log off 60 minutes after the last action (i.e.
if the key pad or a push button has not been used for 60 min.).
Action
Text in display
Comments
YYYY-MM-DD EBL512 CU XX hh:mm:ss
A user definable text.
"Access"
Access code: _
Enter the code (4 digits)
Access code: 
The digits are replaced
() in the display.
NO ACCESS!
The access code was not
correct. Try again.
Perform monthly test
ACCEPT? H1
The access code was
correct. This is menu H1.
Press "A" to accept (to
perform monthly test) or
scroll / jump to the follow-
ing menus (H2-H10).
