MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
112
27.3 Doors open (H4/U3)
The LED "Door open" (L10) is lit, to indicate that one or more doors
are open. See chapter "Door open", page 35.
This menu is a list of all open doors and it is also possible to get a
print-out.
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H4.
Present system status on display and
printer ACCEPT? H4
"A"
Disablement
Printout: (1=yes) U1
Scroll to menu U3.
Doors open
Printout: (1=yes) U3
Press "1" for an automatic
print-out of all "open
doors".
Press "A" for presentation
in the display.
"A"
or
"1"
When "A" is pressed, "open doors" will be shown in the
display. Two examples:
Door open CU 00
L
or
Door open FBP x board x CU xx
L
L = a list in which you can
scroll. If there are no
"open doors" and if
"Return" is pressed, menu
U3 will be shown again.
Printing started. To stop printing press
C and 0 simultaneously ACCEPT?
Press "A" and menu U3
will be shown again.
"Return"
Doors open
Printout: (1=yes) U3
Scroll or press "Return" to
menu H4. Scroll or press
"Return" to log off.
