MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
132
28.7 Display current consumption COM-/BS4-
loop (H5/A6)
The resolution is not very high, i.e. the displayed values give only a
rough idea of the current consumption.
The current consumption (an average value) for each COM loop and
BS4 loop
110
can be displayed.
NOTE! No or very small current consumption can not be presented
correctly / precisely.
Action
Text in display
Comments
"Access"
According to chapter
"Access code for service
(H5)", see page 126.
Scroll to menu A6
Display current consumption on
COM-/BS4-loop ACCEPT? A6
"A"
Select type of loop: 0 (0=COM, 1=BS4)
ACCEPT?
Select type of loop. Press
"A" to accept.
"A"
or
"1", "A"
Display current consumption on
COM-loop: 0, CU: 00 ACCEPT?
Write loop number, (board
number; 0-3) and control
unit number. Press "A" to
accept.
Display current consumption on BS4-
loop: 0, board: 0, CU: 00 ACCEPT?
"A"
Wait......
No reply from control unit.....
If the control unit don't
exist or don't answer, this
message will be shown.
Current consumption on COM-loop: 0
control unit: 00 is xxxx mA
The current consumption
accuracy is ±5 mA.
Current consumption on BS4-loop: 0,
board: 0, control unit: 00 is xxx mA
"Return"
Display current consumption on
COM-/BS4-loop ACCEPT? A6
Scroll or press "Return" to
H5. Scroll or press
"Return" to log off.
110
An Autronica interface board 1584 is required in the control unit.
