27.2 Disablement by time channel (H4/U2)
A list of all disablements by time channel(s) in the system. From this
menu, it is also possible to get a print-out.
NOTE! Other disablements are listed in menu H4/U1.
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H4.
Present system status on display and
printer ACCEPT? H4
"A"
Disablement
Printout: (1=yes) U1
Scroll to menu U2.
Disablement by time channel
Printout: (1=yes) U2
Press "1" for an automatic
print-out of all
disablements in the
system.
Press "A" for presentation
in the display.
"A"
or
"1"
When "A" is pressed, the disablements will be shown in the
display, e.g:
Zone XXX address XX disabled
(by time channel) L
L = a list in which you can
scroll. If there are no
disablements and if
"Return" is pressed, menu
U2 will be shown again.
Printing started. To stop printing press
C and 0 simultaneously ACCEPT?
Press "A" and menu U2
will be shown again.
"Return"
Disablement by time channel
Printout: (1=yes) U2
Scroll or press "Return" to
menu H4. Scroll or press
"Return" to log off.
When scrolling in the list the message "No more zone/addresses disabled by time channel found in the
system" can be shown.
