5 LED indicators and push buttons
LEDs and push buttons can vary according to type and configuration
(convention / country / language).
See also Figure 2, page 16.
LED indicators on the Fire Brigade Panel (FBP)
LED indicator
Indicating
L1
Fire (5 red)
Fire alarms (also Pre-warning, Heavy smoke/heat alarm,
Alert Annunciation alarm, Quiet alarm & Key cabinet alarm)
8
L2
Alarms queued (2 red)
More than one unit / zone have generated fire alarm. Use
push button "Alarms queued" (P1) to scroll.
L3
Extinguishing (red)
Output(s) for extinguishing equipment activated ("Activated
extinguishing").
9
L4
Ventilation (yellow)
Output(s) for fire/smoke ventilation equipment activated
("Activated fire ventilation").
9
L5
Fire brigade tx (red)
Output for fire brigade tx (routing equipment) and/or
corresponding programmable output(s) (i.e. type 4 = routing
equipment) activated.
9
Test of routing equipment in progress (see menu H1).
L6
Operation (green)
The c.i.e. is powered via the rectifier or the battery.
(FBP push buttons on next page)
8
See chapter "Alarm types", page 39. In the New Zealand convention also
"Acknowledged alarm" (ACK).
9
L3, L4 and L5 can as an alternative be programmed to indicate when a
programmable input is activated, i.e. input trigger condition "Activated
Extinguishing", "Activated fire ventilation" and "Activated routing
equipment" respectively (e.g. L5 can be turned on when a programmable
input is activated by an activated routing equipment output).
