MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
110
27 Present system status on display
and printer (H4)
A printer is factory mounted in control unit 1549. Printer 1558 is an
option for control unit 1548.
27.1 Disablement (H4/U1)
A list of all disablements in the system. Also alarm point(s) and/or
zones disabled via the function "Single encapsulated reset" (see page
52) is shown in the list. In this case a zone will be displayed as ZZZ-
00 (i.e. zone number and address 00).
Disablements by time channels are listed in menu H4/U2.
From this menu, it is also possible to get a print-out.
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H4.
Present system status on display and
printer ACCEPT? H4
"A"
Disablement
Printout: (1=yes) U1
Press "1" for an automatic
print-out of all
disablements in the
system.
Press "A" for presentation
in the display.
"A"
or
"1"
When "A" is pressed, the disablements will be shown in the
display. Some examples:
Zone XXX address XX disabled
L
or
Zone XXX is disabled
L
or
Alarm points are disabled by
time channel in CU XX
L = a list in which you can
scroll. If there are no
disablements and if
"Return" is pressed, menu
U1 will be shown again.
a)
On this row can be
shown adding infor-
mation, e.g.: Automatic
re-enablement HH:MM
or (by open door in CU
xx)
Printing started. To stop printing press
C and 0 simultaneously ACCEPT?
Press "A" and menu U1
will be shown again.
"Return"
or
"A"
Disablement
Printout: (1=yes) U1
Scroll or press "Return" to
menu H4. Scroll or press
"Return" to log off.
