Panasonic Eco Solutions Nordic AB
MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
85
be shown for the S/W and text file respectively. Close the dialog
box.
7. Open the "Tools" menu and open the "EBL512 settings" dialog
box. See "3" & "4" above. Click "Read". In the log view will be
shown: "System information has been uploaded". Check the
settings, change when required. See "3" & "4" above. Click
"Download". In the log view will be shown: "System information
has been downloaded". Close the dialog box.
8. Remove jumper "JP1 (BOOT)". Do a reset/restart, see "3" above.
Regarding the reset/restart, see chapter "Restart", page 88.
Follow the same procedure in each control unit.
20.2 Control Units in a TLON network
All control units connected to a TLON network shall have the same
S/W version. If the EBL512 control units shall be used in a mixed
system (see chapter "Mixed system", page 11.), the software version
has to be EBL512 version 2.7.x. In the EBL512 G3 control units the
software has to be EBL512 G3 United version 2.7.x, which has to be
downloaded via Win512 version 2.7.x.
For download of new S/W in each EBL512 control unit, follow the
procedure described above.
Since some control units do not have contact with some control units
during the downloading, the following faults might be generated:
"FAULT: CU xx has no contact with CU xx"
"FAULT: CU xx has wrong information"
The faults have to be acknowledged.
20.3 Earlier S/W version download
For some reason
it might be required to download an earlier S/W
version. This is done the same way as for a new S/W version but with
the following additions:
1. The Win512 version designed for the S/W version to be
downloaded has to be used.
2. After the download, the "EBL512 settings" shall be read, edited
(if required, e.g. the no. of addresses) and then downloaded
again.
3. The dialog box "Please enter your password" might be
displayed.
