Show sensor values and setting alarm algorithm for the Analog
photo electric detector 3304:
Action
Text in display
Comments
"Access"
According to chapter
"Access", see page 92.
Scroll to menu H4.
Present system status on display and
printer ACCEPT? H4
"A"
Disablement
Printout: (1=yes) U1
Scroll to menu U5.
Sensor values
Printout: (1=yes) U5
To make a printout, press
"1", else press "A" to
accept.
"A"
Enter technical number: 000000
Write the sensor's techn.
number and/or press "A"
to accept.
"A"
Sensor: 000001
Momentary: XX.X%/m Weekly: XX.X%/m
This is a list in which
you can scroll or use
"" to see the next
information window for
the selected sensor. Press
"Return" to Enter
technical number.
""
Sensor: 000001 Min: XX.X%/m
Perf Factor: X.XX%/m Max: XX.X%/m
NOTE!
XX.X%/m = XX.X %
obscuration per meter".
Perf Factor: see below
this table.
""
Sensor: 000001
Current algorithm: N-15
N-15 = short name, see
separate table, page 115.
Press "Return" to Enter
technical number or
press "Access" to change
the algorithm.
"Access"
Access code: _
If login was made with
code for level 3, no code
is needed.
Enter code for level 3 (4
digits)
Access code: ****
The digits are replaced
(****) in the display
Change algorithm: (000001 Current N-15)
L-15 L-35 N-15 N-35 H-15 H-35
Use "" or "".
""
Change algorithm: (000001 Current N-15)
L-15 L-35 N-15 N-35 H-15 H-35
