MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
45
Second row: All fire alarms, also several alarm points in one zone,
will be displayed in zone - address order (i.e. up to 15360 alarms).
Press "A". E.g.:
ZONE: 123 LAST: 789 No.: 003
Point: 123-45 00001 of 00005
Point: Zone-address for alarm no. 00001.
""
ZONE: 123 LAST: 789 No.: 003
Point: 234 00002 of 00005
Point: Zone no. for alarm no. 00002.
…and so on.
15.2.2.2 Display faults (X2)
ZONE: 123 LAST: 789 No.: 003
Display faults ACCEPT? X2
Press "A". E.g.:
ZONE: 123 LAST: 789 No.: 003
FAULT: Battery not connected CU xx
Only the fault message, for the fault respectively, is displayed here,
not date, time and "status" information.
15.2.2.3 Display disablements (X3)
ZONE: 123 LAST: 789 No.: 003
Display disablements ACCEPT? X3
Press "A". E.g.:
ZONE: 123 LAST: 789 No.: 003
Zone XXX address XX disabled
15.2.2.4 Disable zone (X4)
ZONE: 123 LAST: 789 No.: 003
Disable zone ACCEPT? X4
Press "A". E.g.:
ZONE: 123 LAST: 789 No.: 003
Disable zone: 000 ACCEPT?
Write zone number and press "A". If more zones are to be disabled,
repeat the procedure.
15.2.2.5 Re-enable zone (X5)
ZONE: 123 LAST: 789 No.: 003
Re-enable zone ACCEPT? X5
Press "A". E.g.:
