Panasonic Eco Solutions Nordic AB
MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
57
FAULT: 1584 Autronica board x, CU xx
(Autronica interface board)
Fault on / no communication to 1584 board No. x in control unit No.
xx. Check address setting and connections on the board. Check
programming (Win512).
FAULT: 1587-board x, CU xx
(External Fire Brigade Panel / DU interface board)
Fault on / no communication to 1587 board No. x in control unit No.
xx. Check address setting and connections on the board. Check
programming (Win512).
FAULT: 24 V for ext. equipment, CU xx
Check the fuses F2 and F4 on the connection board 1555. (Supervised
output S2 is also supplied via F2 and F4).
FAULT: 24 V for routing equipment, CU xx
512
Check the fuses F1 and F3 on the connection board 1555. (Supervised
output S3 is in some conventions / configurations supplied via F1 and
F3). Indicated by LED "L15" blinking.
512 G3
Check the fuse F8 (Output 0) on the 512 G3 main board 5010.
FAULT: 24 V out, output unit xxxxxx
The output current is > 4A. (The output might also be turned off.)
FAULT: 24 V output number x, CU xx
Check the fuses F9 - F12 (Output 1-4) on the 512 G3 main board
5010.
FAULT: AAU xx, 1587-board x, CU xx
AAU=1735 / 1736
The unit is programmed as another type of unit than the SSD says or
