MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
72
FAULT: Short circ. loop x, BS4 x, CU xx
(1584 Autronica interface board, BS4)
Short circuit, or current consumption >167mA, on the BS4 loop
(short circuit isolator is not connected on the loop). Check the loop
NOTE! As long as there is a short circuit, the BS4 loop is disabled.
Each 10
th
minute is an attempt made to re-enable the loop again.
FAULT:Sh-circ loop x, CU xx, CU <->ASF0
FAULT:Sh-circ loop x, CU xx,ASF0<->ASF1
FAULT:Sh-circ loop x, CU xx,ASF1<->ASF2
FAULT:Sh-circ loop x, CU xx,ASF2<->ASF3
FAULT:Sh-circ loop x, CU xx,ASF3<->ASF4
FAULT:Sh-circ loop x, CU xx,ASF4<->ASF5
FAULT:Sh-circ loop x, CU xx,ASF5<->ASF6
FAULT:Sh-circ loop x, CU xx,ASF6<->ASF7
FAULT:Sh-circ. loop x, CU xx, ASF7<->CU
FAULT:Sh-circ. loop x, CU xx, ASF6<->CU
FAULT:Sh-circ. loop x, CU xx, ASF5<->CU
FAULT:Sh-circ. loop x, CU xx, ASF4<->CU
FAULT:Sh-circ. loop x, CU xx, ASF3<->CU
FAULT:Sh-circ. loop x, CU xx, ASF2<->CU
FAULT:Sh-circ. loop x, CU xx, ASF1<->CU
FAULT:Sh-circ. loop x, CU xx, ASF0<->CU
Short circuit on the COM loop "x" (one or more short circuit
isolators are connected on the loop). Check the specified and
isolated segment on the loop (e.g. CU <->ASF0 = between the
control unit and short circuit isolator no. 0). Each 10
th
minute is an
attempt made to re-enable the isolated segment again.
FAULT: Site specific data (SSD), CU xx
Some external influence (or after download) has caused a checksum
fault in the (from Win512) downloaded Site Specific Data (SSD). (An
SSD download is required.). This is very serious. Call for service
personnel/engineer immediately.
FAULT: SSD, AAU xx, 1587-board x, CU xx
AAU=1735 / 1736
There is no SSD (Site Specific Data) downloaded to the unit or
