Panasonic FP0 User Manual

InstallationFP0
6 − 3
6.1 Adding Expansion Units
6.1 Adding Expansion Units
Expansion method
1. Peel the seal on the side of the unit so that the internal
connector is exposed.
Seal
Notes
When peeling the seal on the side of the initial lot products,
the shaded part is exposed. Cut off the shaded part with a pair
of nippers or similar tool so that the internal connector is
exposed.
Cut here.
Shaded part
When removing the shaded part, use a sharp cutting object,
making sure that the shaded part is removed leaving a
smooth surface. Note that failure to remove the shaded part
completely can result in damage to the connector.
next page

Panasonic FP0 Specifications

General

Model	FP0
Communication Ports	RS232C, RS485
Power Supply	24V DC
Operating Temperature	0°C to 55°C
Type	Programmable Logic Controller (PLC)
I/O Points	16 to 128
