Dimensions FP0
13 10
13.7 Connection (between RS232C port and PC)
Layout of Programming Port Pins Common for the FP0/FP2/FPM
1
3
5
42
SG
SD
RD
+5V
1
2
3
4
5
Signal name
Pin No.
The controller’s tool port is provided with the TCS75570121077 connector for FP0
made by Hoshiden Corporation.
13.7 Connection (between RS232C port and PC)
Connection example
Pin No.
S
R
G
Signal name
SD
RD
SG
Pin No.
1
2
3
4
5
6
7
8
Signal name
CD
RD
SD
ER
SG
DR
RS
CS
FP0 RS232C port
PC (DSUB 9pin female)
(DOS/V version)
