Panasonic FP0 - Current Consumed by the Control Unit

Optional Memory FP0
2 − 8
2.2 Specifications
2.2.1.2 Current Consumed by the Control Unit
Unit type Control unit
(The current
consumed by
the control
unit power
supply
connector. If
expansion
units or
intelligent
units are
added, the
current is
increased by
the value
indicated
below. )
Expansion
unit
(The current
consumed by
the expansion
unit power
supply
connector. If a
unit is not
listed below, it
means that it
has no power
supply
connector.)
Input circuit
(The current
consumed by
the input
circuits of the
various units.
The value
indicates the
current that
flows into the
input circuit. )
Output circuit
(The current
consumed by
the output
circuits of the
various units.
The value
indicates the
current used
to drive the
output circuit.
The value
does not
include the
load current
value.)
FP0 Control unit FP0−C10 100mA or less — 25.8mA or less —
FP0−C14 100mA or less — 34.4mA or less —
FP0−C16 40mA or less — 34.4mA or less 28mA or less
FP0−C32
FP0−T32
60mA or less — 68.8mA or less 52mA or less
S−LINK Control
unit
FP0−SL1 150mA or less — — —
FP0 Expansion
unit
FP0−E8X 10mA or less — 34.4mA or less —
unit
FP0−E8R 15mA or less 50mA or less 17.2mA or less —
FP0−E8YR 10mA or less 100mA or less — —
FP0−E8YT/P 15mA or less — — 24mA or less
FP0−E16X 20mA or less — 68.8mA or less —
FP0−E16R 20mA or less 100mA or less 34.4mA or less —
FP0−E16T/P 25mA or less — 34.4mA or less 24mA or less
FP0−E16YT/P 25mA or less — — 48mA or less
FP0−E32T/P 40mA or less — 68.8mA or less 48mA or less
FP0 Intelligent
unit
FP0−A21 20mA or less 100mA or less — —
unit
FP0−A80 20mA or less 60mA or less — —
FP0−A04V 20mA or less 100mA or less — —
FP0−A04I 20mA or less 130mA or less — —
FP0−TC4,
FP0−TC8
25mA or less — — —
FP0−IOL 30mA or less 40mA or less — —
FP0−CCLS 40mA or less 40mA or less — —
Programmable
display unit
AIGT0030
AIGT0032
AIGT0130
AIGT0132
80mA or less — — —
