Panasonic FP0 - Contact Puller Pin for Rewiring

WiringFP0
7 − 19
7.8 Wiring the MIL Connector Type
3. After press-fitting the wire, insert it into the housing.
4. When all wires has been inserted, fit the semi-cover
into place.
semi-cover
Note
If using a MIL connector for flat cables, please specify the order
number AXM110915.
7.8.1 Contact Puller Pin for Rewiring
If there is a wiring mistake or the cable is incorrectly pressure-connected, the contact
puller pin provided with the fitting can be used to remove the contact.
Press the housing against the pressure connection tool so that
the contact puller pin comes in contact with this section.
