1.1 Components
1.1.3 Intelligent Units
Product
name
Specifications Part No. Product No.
FP0 Ther-
l
K, J, T, R thermocouple, Resolution: 0.1 C FP0−TC4 AFP0420
FP0
Ther
mocouple
Unit
K, J, T, R thermocouple, Resolution: 0.1 C FP0−TC8 AFP0421
FP Web−
Server unit
Unit for connecting FP series/RS232C interface and Ethernet
Web−Server function and E−mail sending function
FP−WEB AFP0610
FP0 Analo
g
Input specifications Number or channels
Input range
2 channels
: 0 to 5 V, −10 to +10 V (Resolution: 1/4000)
0 to 20 mA (Resolution: 1/4000)
FP0−A21 AFP0480
FP0
Analog
I/O unit
Output specifications Number or channels
Output range
1 channels
: −10 to +10 V (Resolution: 1/4000)
0 to 20 mA (Resolution: 1/4000)
FP0 A/D
Converter
Unit
Input specifications Number or channels
Input range
8 channels
: 0 to 5 V, −10 to +10 V (Resolution: 1/4000)
0 to 20 mA (Resolution: 1/4000)
FP0−A80 AFP0401
FP0 D/A
Ct
Output specifications Number or channels
Output
range
4 channels
:
10
to
+10
V
(Resolution:
1/4000)
FP0−A04V AFP04121
FP0
D/A
Converter
Unit
p
p
Output range : −10 to +10 V (Resolution: 1/4000)
4 to 20 mA (Resolution: 1/4000)
FP0−A04I AFP04123
1.1.4 Link Units
Product
name
Specifications
Power supply
voltage
Part No.
Product
No.
FP0 CC−
Link Slave
Unit
This unit is for making the FP0 function as a slave station of the CC−Link.
Only one unit can be connected to the furthest right edge of the FP0 expansion bus.
Note: Accuracy will change if an FP0 thermocouple unit is used at the same time.
For details, please refer to the catalog or to the CC−Link Unit manual.
24 V DC FP0−CCLS AFP07943
FP0 I/O Link
Unit
This is a link unit designed to make the FP0 function as a station to MEWNET−F
(remote I/O system).
24 V DC FP0−IOL AFP0732
C−NET
adapter S2
type
(for FP0
side)
This is an RS485 adapter designed to allow use of the Computer link function for
connecting to a host computer via C−NET. It comes with a 30 cm FP0 tool port
cable. A power supply is not required.
— — AFP15402
C−NET
adapter
(RS485)
This is an RS485 adapter designed to allow use of the Computer link function for
connecting to a network−connected PLC via C−NET from a host computer.
100 to 240 V DC — AFP8536
adapter
(RS485)
(for com-
puter side)
g
p
24 V DC — AFP8532
FP
Web−Server
Unit
Connected with FP series PLCs, it conducts Ethernet communication, sends e−mail, and displays the
PLC data on HTML pages.
FP−WEB AFP0610
1.1.5 Power Supply Unit
Product name Specifications Part No.
Product
No.
FP0 Power supply unit
Input voltage: 100 to 240 V AC
Output: 0.7 A, 24 V DC
FP0−PSA4 AFP0634
