Panasonic FP0 - Sample Program

High−speed Counter/Pulse Output/ PWM Output FP0
9 − 14
9.3 High−speed Counter Function
9.3.5 Sample Program
Wiring examples
Encoder
input
Input terminal
X0
Operation
FP0
Operation/Stop
Inverter
Motor
Encoder
X5
COM
Output terminal
Y0
+
−
COM
Operation
start
Y0
Speed
Number of pulse
5,0000
